High Temperature Ducting Hose
High Temperature Ducting Hose
High temperature ducting hose is made from glass fibre with silicone coating. Besides, there are iron rings outside the fabric. Such air duct hose can bear extremely high temperature up to 400℃. Orientflex offers you special high temp duct hose which can withstand max 800℃.
High Temp Ducting Hose Structure
Tube: Silicon coated glass fiber fabric
Clamped profile: Zinc plated steel slice
Temperature: -60℃ to +400℃ (-76℉ to +752℉)
Application: Used for suction of high temperature air, vapors and smoke on engine, dryer, auto, aerospace, shipbuilding, factory and military as bellow and compensator.
High Temp Duct Hose is made from double-ply silicone coated fiberglass fabric, making the hose extremely flexible and wear resistant. It will not be damaged when being dragged on the ground.
Flame Retardant high temp flexible duct hose is a high tempperature duct and the working temperature of which could be 400°C and shortly up to 450 °C.
High Temp Ducting Hose Features
- Very good resistance to high temperature up to 400℃
- Highly flexible and compressible
- Against crushing
- Firm clamping structure
- Good pressure resistance
- Good chemical resistance
- Small bending radius
- Flame retardant
- Kink proof
- Light in weight
Ducting Hose 450℃ Specification
| ID | L | KG | ID | L | KG | ||
| mm | Inch | m/roll | Unit (kg) | mm | Inch | m/roll | Unit (kg) |
| 50 | 2 | 10 | 3.8 | 160 | 6.2 | 10 | 8.5 |
| 63 | 2.5 | 10 | 4 | 180 | 7 | 10 | 10.5 |
| 75 | 3 | 10 | 4.2 | 200 | 8 | 10 | 11 |
| 89 | 3.5 | 10 | 4.4 | 220 | 9 | 10 | 12.55 |
| 100 | 4 | 10 | 5 | 250 | 10 | 10 | 13.5 |
| 115 | 4.5 | 10 | 5.2 | 300 | 12 | 10 | 14.5 |
| 127 | 5 | 10 | 6.25 | 350 | 14 | 10 | 16 |
| 152 | 6 | 10 | 7.55 | 400 | 16 | 10 | 18 |
Ducting Hose 800℃ Specification
| ID | L | KG | ID | L | KG | ||
| mm | Inch | m/roll | Unit (kg) | mm | Inch | m/roll | Unit (kg) |
| 127 | 5 | 10 | 12 | 400 | 16 | 10 | 23 |
| 152 | 6 | 10 | 13 | 500 | 20 | 10 | 26 |
| 160 | 6.2 | 10 | 14 | 600 | 24 | 10 | 30 |
| 180 | 7 | 10 | 15 | 700 | 28 | 10 | 35 |
| 200 | 8 | 10 | 16 | 800 | 32 | 10 | 40 |
| 250 | 10 | 10 | 17 | 900 | 36 | 10 | 45 |
| 300 | 12 | 10 | 19 | 1000 | 40 | 10 | 52 |
| 350 | 14 | 10 | 21 |
